Our Work

Electronic & Mechanical
Design & Manufacturing Examples

Examples of projects fully designed and realised by HGL System’s Engineering Teams

Sophie Turner profile picture

Case Study

Hummingbird48

HGL Dynamics’ largest Data Acquisition conduction cooled Front-End incorporating 16 PCBs and 20 mechanical assemblies. The unit is fully water and fluid proof and tested to DO160G standards for use on large Gas Turbines.

Find out more
Sophie Turner profile picture

Case Study

Airsoft Hop Arm

Created for the popular Airsoft range this is one of the smallest mechanical asssemblies created by HGL Systems.

Find out more
Sophie Turner profile picture

Case Study

HIC Test Pro V1

HGL is involved in Playground Safety Testing with the HIC Test Pro unit which is dropped onto multiple surface types to measure the potential for impact injuries. The unit include integrated Data Acquisition electronics PCBs together with integral batteries, WiFi and Bluetooth.

Find out more
Sophie Turner profile picture

Case Study

HGL Dynamics VESA PC V4

HGL Dynamics markets a range of PCs for use within its software Ecosystem including a VESA mount Core i7 PC with multiple Ethernet ports, twin HDMI displays within a conduction cooled Aluminium Chassis

Find out more
Sophie Turner profile picture

Case Study

HGL FireFly

Designed for ultra-portable Data Acquisition the FireFly incorporates a low-power PC CPU board, an 8-channel DAQ, SSD storage, a rechargeable battery, and a 10” LCD screen all housed within a precision milled conduction cooled chassis.

Find out more
Sophie Turner profile picture

Case Study

HGL Dragonfly8 DIN

HGL provides DAQ and CPU systems for many Industrial Applications and many of these require DIN rail mounting units. The Dragonfy8 DAQ provides the standard capabiliites but with all the connections engineered to be on one end plate olny.

Find out more
